Description
The Grabo Pro Lifter 20 is an advanced vacuum lifting handle equipped with a robust automatic vacuum pump and designed for professionals. The foam rubber vacuum seal on the GRABO Pro Tool is both strong and resistant to loss of vacuum pressure. Once the pressure pump is activated, a strong suction is created which firmly attaches to any non-porous, flat surface. The suction is strong enough to hold loads as heavy as 375 lbs.
The GRABO Pro is extremely easy to use, in order to lift any slab or flat solid material, simply turn on the unit and place it straight onto the surface. The GRABO Pro will then monitor the vacuum created and will automatically power on in the event of vacuum loss, until the vacuum pressure is restored.
Built for Professionals
The GRABO Pro-Lifter 20 is a vacuum lifting handle that is designed for professional use. It is unlike other solutions, as the tool is both portable and handy. It easily lives up to the promise of “Heavy lifting made easy”. Additionally, the Pro-Lifter is effective on both smooth and coarse surfaces. Say good-bye to unreliable, unpredictable, manual suction cups. With the GRABO Pro, you double your work efficiency with the benefit of enhanced safety.
The ergonomic design provides better grip with less fatigue when moving heavy objects, and is an effective vacuum lifter even for dusty, semi-porous or rough surfaces. The tool works great with glass, wood, ceramic tiles, metals and other materials.
Lifting Capacity Table:
Perpendicular Hold | Parallel Hold | |
| Glass: | 375 lbs / 170 kg | 265 lbs / 120 kg |
| Ceramic Tile: | 375 lbs / 170 kg | 265 lbs / 120 kg |
| Metal: | 242 lbs / 110 kg | 242 lbs / 110 kg |
| Plastic: | 220 lbs / 100 kg | 220 lbs / 100 kg |
| Wood: | 220 lbs / 100 kg | 143 lbs / 65 kg |
| Rough Slate: | 176 lbs / 80 kg | 176 lbs / 80 kg |
| Rough Concrete: | 176 lbs / 80 kg | 176 lbs / 80 kg |
| Dry Wall: | 165 lbs / 75 kg | 143 lbs / 65 kg |
GRABO Pro Lifter 20 Features:
- Digital display to show maximum weight that the GRABO Pro can safely lift at that very moment
- Weight display in both lbs and kg’s
- Smart digital pressure sensor
- Effective on both non-porous, semi-porous or rough surfaces
- Lifting is automated and deactivated with the press of a button
- Automatic sensor provides the optimum level of suction during use
- Digital display on grip handle shows pressure applied in both bars and psi
- Pressure sensors automatically enable suction so you don’t even need to turn the vacuum pump on or off
- Ergonomic, comfortable design
- Hold loads as heavy as 375 lbs
GRABO Pro Lifter 20 Kit:
The GRABO Pro comes as a complete unit, with pre-installed battery and vacuum seal. Additionally, other accessories come with the kit including a multi-socket charger and heavy-duty carry bag.
Package Contents:
- 1 GRABO Pro Tool (2021 Model with Digital Display)
- 1 Multi-Socket Charger
- 1 Seal (Pre-installed on the tool)
- 1 Battery (Pre-installed on the tool
- 1 Tough Oxford fabric carry bag
- Operator manual in English
GRABO Pro Specifications:
| Model: | GRABO PRO-LIFTER 20 |
| Battery: | 14.8 VDC | 2600mAh Li-Ion |
| Rated Power (Watts): | 16 |
| Charger Input Voltage: | 100 – 240 VAC | 50/60Hz |
| Battery Charging Time: | ~2 Hours* |
| Non-Stop Running Time (Full Charge): | ~1.5 Hours* |
| Running Cycles (On Full Charge): | 900 On-Off Cycles of 10 Seconds* |
| Stand-By-Mode (Charge Hold): | 30 Days* |
| Expected Pump Service Life: | 100,000 On-Off Cycles / 800+ Hours Continuous |
| Rated Air Flow: | 0.7 cfm (20 L/min) |
| Maximum Vacuum Rate: | 11.6 Psi (0.8 Bar, 80kPa) |
| Maximum Lifting Capacity: | 375 Lbs (170Kg) |
| Dimensions (LxWxH): | 11.77″ x 7.22″ x 4.76″ (300mm x 184mm x 121mm) |
| Net Weight (With Battery): | 3.2lbs (1.5 Kg) |
| Working Temperature: | 32°F – 140°F (0°C – 60°C) |
| Applicable Surface Type: | Peak/Valley heights less than 0.1″ (3mm) and Arc less than 5° |
* While the specified values are expected, they are approximations and as such, different circumstances can cause results to vary
